Hose Connectors
 Hose Connectors and Push-On Hose Fittings

 Hose Connectors and Push-On Hose Fittings

  Applications
  Pneumatic system, Automotive industry
  Features
  King nipple type design Stainless Steel, Brass.
  Easy assembly without socket
  simply replaced with hoses.
  Specification
  Maximum Operating Pressure :
  362 psig (25 barg) @ 70 F (20 C)
  Operating Temperature Range :
  -560 F (-490 C) to 3000F (1490 C)

  Instrument Thread Fittings

Instrument Thread Fittings


  Instrument Thread Fittings

  Applications
  General service, instrumentation
  Features

ASME B1.20.1 (NPT)
  Stainless Steel, Brass, Carbon Steel According to
  ASME B31.1 & B31.3
  Rolled male threads for extra strength
  All exposed threads protected to prevent damage.
  Specifications

Maximum Operating Pressure :
  10000 psig (680 barg) @ 1000 F (38 C)
   Operating Temperature Range :
  -3250 F (-1980 C) to 12000 F (6480 C)

   Instrument Weld Fittings

  Applications

Corrosive fluids, Temperature cycling, Vibration
  Features
  Tube socket weld Stainless steel, Brass, Carbon
  Steel According to ASME B31, 1& B31.3
  permanently welded tubing system. All pipe ends
  wall thickness are SCH. 80 or greater.
  Specifications
  Maximum Operating Pressure :
  10000 psig (680 barg) @ 1000 F (380 C)
  Operating Temperature Range :
  -325 F (-1980C) to 1200 F (6480 C)


 Hydraulic Flanges
  Hydraulic Flanges (SAE J518/ISO 6164)
  Hydraulic Flanges (SAE J518/ISO 6164)
  Applications
  High pressure hydraulic system
  Features

O-ring face to face design stainless steel,
  A105 According to SAE J518/ISO 6164 very
  easy repair and maintenance useable with
  pipes or hoses
  Specification
  Maximum Operating Pressure :

6000 psig (413 barg) @ 100F (38 C)
  Operating Temperature Range :

-130F (-250C) to 3920 F (2000C)
